- Voltage
- 48V
- IP Rating
- IP67
- Cut
- 10cm
- Max Run
- 30m
- Warranty
- 4 Year
Cool White Neon Flex 6000K 48V 16x16mm Top Bend IP67 Waterproof 50m
SKU: NFCW48V1616
-
Corner Bend
-
Side Bend
-
4 Years
-
30m Run
Encrypted & secure checkout
Description
Engineered for precision and performance, our 16x16mm Top Bend / Vertical Bend LED Neon Flex operates at 48V and is ideal for a wide range of vertical lighting applications. Made from high-quality silicone, it offers excellent flexibility and durability, making it perfect for architectural features, retail displays, signage, and high-end residential lighting.
This professional-grade neon flex delivers smooth, non-spotting illumination and features 10cm (100mm) cut points, allowing for easy customization on site. With a low power consumption of just 9W per metre, it supports continuous runs of up to 50 metres from a single-side power feed, offering efficiency and versatility for large-scale installations.
The IP67-rated LED Neon Flex is designed for both indoor and outdoor applications, featuring a durable rear-entry cable for easy installation.
Designed to meet the standards of lighting designers, contractors, and electricians, this neon flex combines premium materials with consistent, high-performance output—elevating any project with a clean, seamless light line and a refined, modern finish.
Power Supply is not included, you need to buy the clips and the power supply separately.
Specifications
- Voltage: 48V DC
- Colour: Cool White 6000K
- Typ. Power: 9W/m
- LEDs per metre: 120 LEDs
- Cut Points: 100mm (10cm)
- CRI: >80
- Beam Angle: 120°
- Dimensions: 16mm x 16mm
- Lumens per metre: Up to 750 lm
- Warranty: 3 Years
- IP Rating: IP67 (suitable for indoor and outdoor use)
- Continuous Run: 50m run (one sided)
- Warranty: 3 years
The lights are custom cut as per your specific requirements.
- Product Type
- LED Neon Flex
- Colour
- Cool White 6000K
- IP Rating
- IP67 Waterproof
- Voltage
- 48V
- Watts Per Metre
- 9 Watts
- LEDs Per Metre
- 120
- Max Run Length
- 30m
- CRI
- >80
- Dimensions
- 16x16mm
- Warranty
- 4 Years
Specifications
- Product Type
- LED Neon Flex
- Colour
- Cool White 6000K
- IP Rating
- IP67 Waterproof
- LEDs Per Metre
- 120
- Continuous Run
- 30m
- Voltage
- 48V
- Watts Per Metre
- 9 Watts
- Metres
- 50m roll
- Dimensions
- 16x16mm
- Width
- 16mm
- Depth
- 16mm
- Bending Angle
- Top / Vertical Bend
- Lumens Per Metre
- 750 lm
- Cut Points
- 10cm
- Operating Temperature
- -30°C to 50°C
- LED Type
- 2835
- Average LED Life Hours
- 50,000
- Continuous Operating Hours
- 15 hours
- Max Bending
- 2cm
- Shape
- Flat Shape
- Certification
- UKCA, CE, RoHS
- Material
- Silicone
- CRI
- >80
- Warranty
- 4 years
- Brand
- ATOM LED
Delivery & Returns
On 97% of products — Royal Mail 48-hour tracked
Mainland UK orders over £90 — order by 1pm, Mon–Fri
30-day returns window — free returns on faulty products
01952 370028 · Mon–Fri 9am–5pm
Shipping
Free UK delivery on 97% of products is sent via Royal Mail 48-hour tracked.
Free next day delivery on Mainland UK orders over £90 (order by 1pm, Mon–Fri).
Orders placed before 1pm UK dispatch the same working day from Telford. Friday 1pm is the cut-off for Monday delivery, excluding paid Saturday Delivery and bank holidays.
Saturday Delivery is available as a paid option at checkout.
Large orders and pallet shipments: call 01952 370028 for a quote.
For more information see our detailed Shipping Page.
International Shipping
Northern Ireland shipping is charged at manual rates depending on shipment weight. International shipping uses manual zone rates at checkout.
Returns & Refunds
The 30-day return window applies to non-customised stock items returned in their original, unopened, uncut condition with original packaging. Eligible items include:
- Standard LED strip lights supplied as 5-metre rolls
- Straight aluminium profiles
- Power supplies and drivers
- Accessories (connectors, controllers, dimmers, end caps)
Custom-cut and bespoke orders (made-to-measure strip, custom-spec drivers, custom-length profiles, special-order items) are non-returnable unless faulty.
Faulty products qualify for free returns — we cover the return postage and either replace the item or refund the full cost including original delivery.
Refunds are processed within 5–10 working days of receiving the returned item.
For more details see our Returns & Refunds page.
Reviews
Frequently Asked Questions
What is the difference between IP65, IP67, and IP68?
IP65 handles surface splashes only and is not suitable for UK outdoor conditions or bathroom wet zones under BS7671. IP67 is rated for temporary immersion and covers outdoor garden installations, most bathroom zones, and exposed architectural features. IP68 handles continuous submersion for ponds, fountains, and fully exposed outdoor applications. For most UK garden and decking projects, IP67 is the correct choice.
Can I cut this product to a custom length?
Yes. ATOM LED products can be cut at the marked cut points without voiding the warranty. Many competitors restrict cuts to 50–100mm intervals, which wastes offcuts on tight custom runs. Use sharp scissors or a craft knife for a clean cut, then seal the end with a suitable end cap.
What size driver do I need?
Multiply the total metres by the wattage per metre, then add 20% headroom. For example: 10 metres of 24V neon flex at 9W/m = 90W total, so you need a minimum 108W driver. Never load a driver above 80% capacity for long-term reliability.
Should I choose 12V, 24V, or 48V?
Choose 12V for caravans, cars, boats, and any project powered by a 12V battery. Choose 24V for most home and trade installs where you need dependable run length with lower voltage drop. Choose 48V for longer architectural runs where extra distance and single-feed flexibility matter. For underwater or submerged installs, use IP68 Waterproof lights and the correct driver for that product; do not use 48V underwater.
What is your warranty?
ATOM LED offers product-specific warranties: up to 7 years on single-colour COB strip, 5 years on RGB and RGBW COB strip, and 4 years on LED neon flex. The warranty covers manufacturing defects. Call 01952 370028 for warranty claims.
Do you offer free delivery?
Yes. Free UK delivery on 97% of products via Royal Mail 48-hour tracked. Free next day delivery on Mainland UK orders over £90 (order by 1pm, Mon–Fri).
