- 4096 levels 0-100% dimming smoothly without any ash.
- Match with RF 2.4G single zone or multiple zone dimming remote control.
- One RF controller accept up to 10 remote control.
- Auto-transmitting function: Controller automatically transmit signal to another controller with 30m control distance.
- Synchronize on multiple number of controllers.
- Connect with external push switch to achieve on/off and 0-100% dimming function.
- Logarithmic or linear dimming curve selectable.
- PWM frequency 500Hz, 2kHz, 8kHz or 16kHz selectable.
- Over-heat / Over-load / Short circuit protection, recover automatically.
- Light on/off fade time 3s selectable.
Match Remote Control (two match ways)
Use the controller’s Match key
- Match: Short press match key, immediately press on/off key (single zone remote) or zone key (multiple zone remote) on the remote. The LED indicator fast flash a few times means match is successful.
- Delete: Press and hold match key for 5s to delete all match, The LED indicator fast flash a few times means all matched remotes were deleted.
Use Power Restart
- Match: Switch off the power, then switch on power, repeat again. Immediately short press on/off key (single zone remote) or zone key (multiple zone remote) 3 times on the remote. The light blinks 3 times means match is successful.
- Delete: Switch off the power, then switch on power, repeat again. Immediately short press on/off key (single zone remote) or zone key (multiple zone remote) 5 times on the remote. The light blinks 5 times means all matched remotes were deleted.
Push Dim Function:
- Push Dim Function ● Short press: Turn on or off light. ● Long press (1-6s): Press and hold to step-less dimming, With every other long press, the light level goes to the opposite direction. ● Dimming memory: Light returns to the previous dimming level when switched off and on again, even at power failure. ● Synchronization: If more than one controller are connected to the same push switch, do a long press for more than 10s, then the system is synchronized and all lights in the group dim up to 100%. This means there is no need for any additional synchrony wire in larger installations. We recommend the number of controllers connected to a push switch does not exceed 25 pieces, The maximum length of the wires from push to controller should be no more than 20 meters.
Light On/Off Fade Time
- Long press match key 5s, then short press match key 3 times, the light on/off time will be set to 3s, the indicator light blink 3 times. Light on/off fade time Long press match key 10s, restore factory default parameter, the light on/off time also restore to 0.5s.
- Input voltage - 12-48V DC
- Output voltage - 12-48V DC
- Input current - 15A@12/24V - 10A@36/48V
- Output Power - 180W@12V - 360W@24V - 360W@36V - 480W@48V
- Output Type - Constant Voltage
- Scenario Mode - 44 default and 10+ customizations
- Input Signal - RF 2.4GHz + Push Dim
- Control Distance - 30m(Barrier-free space
- Dimming Gray Scale - 4096 (2^12) levels
- Dimming Range - 0 -100%
- Dimming Curve - Logarithmic or linear
- PWM Frequency - 500Hz, 2kHz, 8kHz, 16kHz
- Operation temperature - Ta: -30OC ~ +55OC
- Case temperature (Max.) - T c:+65 C
- IP rating - IP20
- Warranty - 5 years
- Certification - CE,EMC,LVD,RED
- Size - L120 x W43 x H35mm
